Smooth Flutes

Concrete Textures and Form Liner Patterns

Whether you want to create a geometric patterned concrete wall, a custom rock texture, or design an art motif that will be an architectural showpiece, or anything in between, we’ll create the concrete form liner for the job.

Each concrete form liner is designed for your application with consideration for ease of use, flexibility, and scale. Patterns can be made to match side by side, top to bottom, staggered/offset, and even rotating 180 degrees.

Browse our extensive library below.

View Smooth Flutes Image Gallery.

1702

302 Standard Spec Flute

1.5" depth
4" C-C
1.5" peak
1.5" valley
1703

Filmore Flute

1.5" depth
6" C-C
2" peak
3" valley
1704

304 Standard Spec Flute

0.75" depth
2" C-C
0.75" peak
0.75" valley
1705

305 Standard Spec Flute

0.5" depth
1.5" C-C
0.5" peak
0.5" valley
1706

303 Standard Spec Flute

1.5" depth
2" C-C
0.5" peak
0.5" valley
1707

Lincoln Flute

0.75" depth
6" C-C
2.5" peak
2.5" valley
1708

1/2" Sine Wave

0.5" depth
1" C-C
0.5" peak
0.5" valley
1709

Houston Flute

0.75" depth
1.5" C-C
0.5" peak
0.5" valley
1710

Connecticut Flute

0.5" depth
2" C-C
0.875" peak
0.875" valley
1712

Utah Flute

1-1/2” depth
6" C-C
2-1/2" peak
2-1/2” valley
1713

Colorado Flute

1.5" depth
3" C-C
1" peak
1" valley
1714

Wilson Flute

1" depth
2" C-C
0.75" peak
0.75" valley
1715

San Diego Flute

0.25" depth
0.594" C-C
0.25" peak
0.25" valley
1716

Waimea Flute

0.50" depth
8" C-C
7" peak
1" V-Groove valley
1717

Santa Fe Flute

1.5" depth
6" C-C
1.125" peak
3.875" valley
1718

Arizona DOT Random Flute

1.5" depth
random C-C
random peak
random valley
1720

Taft Flute

1.5" depth
5" C-C
2.5" peak
1.5" valley
1721

307 Standard Spec Flute

0.75" depth
4" C-C
2.5" peak
1.5" valley
1722

1/4" Sine Wave

0.25" depth
0.5" C-C
1723

Wyoming Flute

0.5" depth
6" C-C
4.5" peak
0.5" valley
1724

Mesa Flute

1.5" depth
4.5" C-C
1" peak
2.5" valley
1725

1725 Walters Flute

0.375" depth
1.50" C-C
0.75" squared peaks
0.75" valleys
1726

Orlando Flute

0.75" depth
3" C-C
1" peak
1.5" valley
1730

Colfax Flute

0.75" depth
3" C-C
1.5" peak
1" valley
1731

Random 3/16" Striation

0.1875" depth
random C-C
random peak
random valley
1732

Random Reveal

1" depth
random C-C
random peak
random valley
1734

Adrian Flute

0.75" depth
4" C-C
1.75" peak
1.75" valley
1738

3/8" Flute

0.5" depth
1" C-C
0.375" peak
0.375" valley
1739

Gila Flute

1.25" depth
6" C-C
3.5" peak
1" valley
1740

See9

0.875" depth
2.667" C-C
1741

Perris Flute

0.75" depth
3" C-C
1" peak
1" valley
1744

Varying Striations

0.25" depth
C-C varies
peak varies
valley varies
1745

Standard Spec 309

0.75" depth
3" C-C
0.75" peak
1.75" valley
1751

MTU Flute

1" depth
2" C-C
0.5" peak
0.5" valley
1752

Long Ripple Rib Flute

0.0625" depth
0.375" C-C
1753

Narrow Rippled Rib

0.0625" depth
0.125" C-C
1760

Maui Flute

0.25" depth
1.5" C-C
0.625" peak
0.75" valley
1761

1" Sine Wave

0.5" depth
2" C-C
1765

Franklin Flute

0.5" depth
1.25" C-C
0.375" peak
0.375" valley
1766

6" Sine Wave

1" depth
6" C-C
1767

Chestnut Flute

0.875" depth
6" C-C
4" peak
1" valley
1771

Sawtooth

0.75" depth
1.50" C-C
1.50" wide triangles
1774

Bryan Flute

5" C-C
1-1/2" depth
1775

Spare Rib Flute

1" depth
4" C-C
1.25" peak
2.25" valley
1777

Textured Grave Stake

0.75" depth
random boards
1781

Arizona DOT Random Flute Modified

1" depth
1"-5.5" peak
2"-7" valley
1784

Pinnacle Flute

1" depth
1.5" C-C
1786

3/4" Sine Wave

0.75" depth
2" C-C
1789

WTP Flute

1.5" depth
4.5" C-C
3" peak
0.5" valley
1791

Boat Ramp Flute

0.6875" depth
1.45" C-C
0.0" peak
0.0" valley
5732

6/2 Swell

2" depth sine wave
6" C-C
5730

Map Flute

0.5" depth
12" C-C
11" peak
0.5" valley
5733

Machado Flute

.75" depth
5-1/2" C-C
4" peak
1" valley
5754

5754 Carlsbad Flute

1.5" depth
4" pattern repeat
5939

MBTA Pyramid (Custom)

1" depth
All endpoints to middle of square 4"
5773

Kings Flute

0.75" depth
12" C-C
1.5" triangular valley
