1101

Standard Spec Rib

0.75" depth
1.5" C-C
0.5" peak
0.5" valley
1102

Corea Flute

1.75" depth
3" C-C
1" peak
1" valley
1103

Stanton Rib

1" depth
2" C-C
1" peak
0.25" valley
1104

Denver Rib

1.5" depth
3.375" C-C
2" peak
0.75" valley
1105

Las Vegas Rib

1" depth
2" C-C
0.5" peak
0.5" valley
1106

Dover Rib

1" depth
2.5" C-C
0.875" peak
0.875" valley
1106A

Dover Flute

1.25" depth
2.5" C-C
0.75" peak
1" valley
1201

Rough Sawn 8" Wood

6.875" and 8"
alternating planks
1" depth
1202

Grape Stake

2" board width
0.75" depth
1203

Barnwood

2.75"-6.875" board width
0.0625" depth
1204

Random 3/8" Board

5.25"-9.25" board width
0.375" depth
1205

Smooth Ship Lap

6" width
0.50" depth
1207

Cedar Plank

4" board width
0.3125" depth
1208

Rough Sawn Random Boards

1.625"-8.75" board width
0.25" depth
1209

6" Pine Wood Grain

5.75" board width
0.1875" depth
1210

Random Pine Wood Grain

1.625"-8.75" board width
0.625" depth
1212

Light Wood Grain 581

3.5" board width
0.25" depth
1213

Weathered Tongue and Groove

8" board width
0.25" depth
1214

Board & Batten

10" and 2" board and batten
0.75" depth
1215

6" Woodgrain Shiplap

6" board width
0.75" depth
1216

Weathered Wood Grain

4" board width
0.25" depth
1217

Random Wood

1.75" to 7.50" width
0.75" depth
2.25" to 6.25" mortar joints
May require backing
1218

3" Rough Cut Board

3" width
0.125" depth
1221

Stepped Wood Planks

1.5" board width
0.75" depth in two steps
1222

Heavy Sawn Wood

1.75" to 5" width
0.25" depth
1224

Historic Wood Grain

5.50" width
~0.125" to ~0.1875" depth
1224_Plastic

Historic Wood Grain (Plastic)

~5.50" pattern repeat
~0.125" to ~0.1875" depth
1226

Random Cedar Board Form

2.875"-10.75" board width
0.625" depth
1227

Spec Wood

0.75" depth
12" C-C
2.50" squared peaks
9.50" valleys
1231

Split Cedar Shingle

4"-8" board width
0.5" depth
1235

Wire Brush Grooved Textured Wood

2.75"-4.75" board width
0.25" depth
1236

Native Wood

7.5" board width
0.25" depth
1240

6" Wood Grain Shiplap

6" board width
1" depth
1242

Barnwood with Reveal

2.5"-9" board width
0.25"-0.5625" depth
1244

Pirate Plank

3" width
~0.25" depth
1245

California Board

0.25" depth
9" C-C
1" mortar joints
8" boards
1248

Wood Grain Reveal

1.50" depth
12" C-C
6" peaks
6" valleys
1249

Mendota Redwood

3.5"-5.5" board width
0.25" depth
1250

6" Rough Sawn Plank

5.5" board width
0.75" depth
1251

6" Tongue & Groove

0.25" depth
6" C-C
5.50" plank widths
0.50" mortar joints
1252

Weathered Barnwood

0.25" depth
1253

6" Wood Plank with Reveal

6" board width
0.375" depth
1254

Rough Cedar Plank

4.36" width
0.125" depth
1255

Coyote Wood

6" board width
0.375" depth
1259

Cabin Board

0.1875" depth
6" C-C
0.125" mortar joints
1264

Seattle Ship Lap

0.50" depth
4" C-C
1265

Reckwood

0.50" depth
Random curved flutes
1267

8" Woodgrain Plank Ship Lap

0.50" depth
8" C-C
1268

LA Plank

3.25" pattern repeat
0.1875" max depth
1269

Knotty Plank

0.1875" depth
5.50" planks
0.0625"-0.125" mortar joint
1272

Wood with Reveals

6" pattern repeat
0.25" max depth
1301

Slump Block

4"x16" brick size
0.375" depth
1302

Old Brick

3"x8" brick size
0.1875" depth
1303

Standard Spec Smooth Brick

2.25" x 7.75" brick size
0.375" max depth
1305

Random Size Split Face Block

4" to 16" block sizes
1.125" depth
1.50" mortar joints
1306

8" x 2-1/2" Smooth Brick

8"x2.5" brick size
0.25" depth
1309

Richtex

3.6875"x11.6875" brick size
0.125" depth
1311

12" Used Brick Running Bond

2.5"x11.5" brick size
0.375" depth
1314

Paraloam Brick

Running Bond with 2.50" x 9.50" brick sizes
0.3125" depth
0.50" mortar joints
1316

LIE Sawtooth Brick

5.60" C-C width
3" C-C height
1317

3" x 10" Rough Wire Brick Running Bond

3"x10" brick size
0.375" depth
1319

Weathered Brick

3.625" x 11.625" brick sizes
0.25" depth
0.375" mortar joints
1321

Vertical Stacked Brick

3.625" x 11.625" brick sizes
0.25" depth
0.375" mortar joints
1323

4" x 12" Rough Wire Brick Running Bond

4"x12" brick size
0.25" depth
1325

3" x 8" Rough Brick Running Bond

2.5"x7.625" brick size
0.1875" depth
1326

Aggrebrick

2.25" x 7.625" brick sizes
0.375" depth
0.375" vertical mortar joints
0.417" horizontal mortar joints
1330

Roller Brick

2" x 11.625" smooth bricks
0.375" max. depth
0.375" mortar joints
1337

Closure Brick

4" x 8" smooth bricks
0.25" max. depth
0.375" mortar joints
1340

Aggrebrick Soldier Course

2.25" x 7.625" brick sizes
0.375" depth
0.375" vertical mortar joints
0.417" horizontal mortar joints
1341

Aggrebrick Herringbone

2.25" x 7.625" brick sizes
0.375" depth
0.375" horizontal mortar joints
1402

12" x 12" Split Face Block

12" x 12" C-C split face blocks - stacked bond
0.625" depth
0.375" mortar joints
1403

8" x 8" Split Face Block

8"x8" C-C blocks
0.75" depth
1404

8" x 16" Standard CMU Block

8"x16" C-C blocks
0.375" depth
1407

8" x 16" Split Face Block

8"x16" block size
0.375" depth
1408

CMU Sand Block

7.50" x 15.50" block sizes
0.375" depth
0.50" mortar joints
1409

8" x 16" Split Face Stackend Bond

8"x16" block size
0.375" depth
1413

8" x 8" Standard CMU Block

8"x8" block size
0.375" depth
1425

Canon Bond Block

random block size
1.5" depth
1426

American Smooth Face Block

15.50" x 3.50" smooth running block bond sizes
0.125" depth
0.50" mortar joints
1427

Custom Canon Bond Block

21" x 45" running block bond sizes
1.50" depth
3" mortar joints
1429

Split Rib Block

8"x2.75" block size
0.75" depth
1430

Cranston Split Block

11.5"-24" block size
1.5" depth
1431

LS Block

23.625" W x 15.625" H block sizes
0.375" depth
0.4375" mortar joints
1433

Mountain Creek Block

15.50" x 39.50" block sizes
1.50" depth
0.50" mortar joints
1439

12" x 24" Smooth Face Block

23.625" W x 11.625" H block
0.375" max depth
24" horizontal C-C
12" vertical C-C
1501

Dry Stack Fieldstone

Rock height varies
Rock width varies
1.5" depth
1502

Ashlar Stone

2.5"-11" rock height
2.5"-17" rock width
1.25" depth
1503

Red E Cobblestone

9" rock height
11"-18" rock width
1.5" depth
1505

Madera Flagstone

7"-24.5" rock height
7.5"-24" rock width
1.75" depth
1506

Random Block Ashlar Stone

4"-42" rock width
1.5" depth
1508

Large Dry Stack Fieldstone

2"-6" rock height
5"-23" rock width
1.25" depth
1510

Rocky Mountain Flagstone

4"-40" rock width
2" depth
1511

Devils Slide Strata

rock height varies
rock width varies
3" depth
1513

SC Fractured Granite

1" depth
1515

SC Ashlar

8.25"-26" rock height
3.75"-14" rock width
1.5" depth
0.75" mortar joint
1517

St. Marys Ashlar

8.25"-26" rock height
3.75"-14" rock width
1.5" depth
1519

Tallahassee Ashlar

7"-28" rock width
1" rock depth
~3/4" to 1" joint width (varies)
1520

Batavia Random Fieldstone

3"-26" rock width
2.5" depth
1521

Tahoka Stone

6.5"-13" rock height
9"-30" rock width
2" depth
1523

RE Ashlar

8"-25.5" rock width
5"-12" rock height
1.5" depth
1524

San Diego Dry Stack

3" to 7.50" rock heights
7.50" to 28" rock widths
1" depth
0.50" to 0.5625" mortar joints
1526

La Sierra Fieldstone

5" to 11" rock heights
6" to 29" rock widths
2" depth
0.50" to 0.75" mortar joints
1534

Large Running Bond Stone

7.25"-22" rock width
1.5" depth
1535

Amboy Cut Stone

2" depth
1536

Mammoth Cobblestone

3"-6" rock width
1.25" depth
1537

Colorado Red Flagstone

5"-30" rock height
2.5"-13" rock width
1.5" depth
1538

Cut Textured Stone

16.5"-56" rock height
13" rock width
1.5" depth
1541

Rush Creek Ashlar

Up to 30" rock width 2" depth (1.5" in plastic)
1542

Portland Dry Stack

4" to 8" rock heights
5" to 24" rock widths
1.50" depth
0.75" mortar joints
1544

Ashlar Dry Stack

5"-26" rock width
0.75" depth
1545

Kona Rock

5.25"-18.5" rock height
5.5"x17.25" rock width
0.75" depth
1546

American Cut Stone

14" rock heights
14" to 47" rock widths
3" depth
0.75" mortar joints
1547

Colorado Flagstone

8"-14" rock width
2.5" depth
1548

Chester Dry Stack

5"-26" rock width
1.75"-2.5" depth
1549

Chiseled Limestone

12" rock height
24" rock width
1.5" depth
1550

Fractured Basalt

2" depth
1553

Cut Ashlar

3.25"-12" rock height
6"-32" rock width
0.75" depth
1555

Navasota Ashlar Stone

rock width up to 30"
1.625" depth
1556

Franklin Aged Ashlar

3"-25.375" rock height
1"-9.5" rock width
0.75" depth
1558

Liberty Dry Stack

3.5"-25.25" rock height
1.5"-10.5" rock width
1.375" depth
1570

Klamath Dry Stack

2"-23.5" rock height
1.5"-13.5" rock width
1" depth
1572

Ashlar Cobblestone

3"-7.25" rock height 5.75"-6" rock width 0.5" depth
1573

Independence Ashlar

10"-33.5" rock width
1.5" depth
1577

Random Cobblestone

1-1/2" depth
0.75" mortar joint
3"-8" rocks
1579

Summit Rock

3"-18.25" rock height
2.75"-9.5" rock width
1.25" depth
1580

Lincoln Dry Stack

1-3/8" depth
4"-30" stones
1581

Washington Dry Stack

1.5"-7" rock height
4"-24" rock width
1" depth
1582

Stone Ground Granite

0.5" depth
1585

Oneida Rectangular Stone

24"-72" rock height
23" rock width
1.5" depth
1587

California Dry Stack

3"-24" rock width 1.25" depth
1587A

1587A California Dry Stack

3"-24" rock width
1.25" depth
1587AB

1587A/B California Dry Stack

3"-24" rock width
1.25" depth
1587B

1587B California Dry Stack

3"-24" rock width
1.25" depth
5501

American 12"x24" Stone

11" rock heights
23" rock widths
1.625" depth
1" mortar joints
5502

American 24"x48" Stone

23" rock heights
47" rock widths
1.625" depth
1" mortar joints
5503

American Stone

15⁄8" (41mm) deep rib
10" to 30" stones
6" coursing
5527

Cut Random Stone

2" (50mm) deep cut stone
3⁄4" mortar joint
14" coursing
Note: 44.25" panel width
5533

Keystone Ashlar

7" to 23" W x 3" to 14.4" H stones
1.25" depth
0.50" to 0.75" mortar joints
5535

Fall River Cut Stone

2" depth
1" mortar joints
5536

Cracked Limestone

1.50" depth
0.50" to 0.75" mortar joints
5537

Custom Random Fieldstone

8" to 24" rock sizes
0.75" depth
0.50" to 1" mortar joint
1505 modified to 0.75" depth
5538

Arizona River Rock

4" to 12" rock heights
4" to 12" rock widths
1.50" depth
0.50" to 1" mortar joints
5550

Kane Long Stone

3.61" to 17.54" W x 3.61" to 7.61" H stones
0.50" maximum depth
0.25" maximum texture relief
0.39" mortar joint
5552

Colorado Granite

7" to 28" rock heights
5.50" to 18.50" rock widths
3.50" depth
0.50" to 0.75" mortar joints
5554A

Coastal Fieldstone A

1.60" to 20" W x 1.50" to 10.60" H rocks
Individual rock shapes may vary
1.50" maximum depth
Panels available in 4' x 8'
5554B

Coastal Fieldstone B

1.60" to 20" W x 1.50" to 10.60" H rocks
Individual rock shapes may vary
1.50" maximum depth
Panels available in 4' x 8'
5558

Custom Cobblestone

~12" maximum stone size
2" maximum depth
5561

CG American Stone

10" to 30" width stones
1" maximum depth
0.50" mortar joint
7" vertical C-C
5563

Coastal Basalt

2" maximum depth
5565

Spec Ledgestone

1/2” maximum depth
~3"-12" width
1"-4" height
5566

Virginia Rock 2"

1/8" - 1” mortar joint
2" depth
6” to 30" width rocks
3-7/8" to 17-1/4" height rocks
5567

Virginia Rock 1"

1/8" to 1” mortar joint
1" depth
6” to 30" width rocks
3-7/8" to 17-1/4" height rocks
5578

Desert Cobble

1” maximum depth
~2"-24" width
1601

Light to Medium Sandblast

0.125" depth
1602

Heavy Sandblast

0.25" depth
1603

Bush Hammer

1" depth
1605

Broom/Rake Texture

0.0625" depth
1606

Random Large Aggregate

0.25" depth
0.75" rock size
1607

Riverbed Aggregate

0.1875" depth
1608

Split Slate

0.25" rock size
1609

1" Round Stone

0.5"-1.5" depth
0.5" rock size
1613

Fractured Concrete

0.75" rock size
1614

Smooth Sheet

Smooth sheet
1615

Medium Bush Hammer

0.25"-0.5" depth 0.375" rock size
1616

Stucco Texture

Stucco texture
1617

Crushed Stone

Crushed stone
1621

Tasman Slate

0.125" depth
1626

Kleen Slate

0.75" rock size
1628

Colorado Tile

0.375" depth
16" C-C tiles
0.375" mortar joint
1630

Pollock Stucco

0.125" depth
1632

Contee Granite

0.3125" depth
1634

KL Medium Sandblast

0.1875" depth
1636

Texas Sandblast

0.125" to 0.1875" depth
1637

Split Face Granite

0.50" average depth to
0.75" maximum depth
1639

Erie Slate

0.25" max depth
1651

Light Sandblast

~0.0625" depth
1655

Striated Drag

1/8” (3mm) depth
1669

Southwest Split Face

0.625" average depth to
1.25" maximum depth
1702

302 Standard Spec Flute

1.5" depth
4" C-C
1.5" peak
1.5" valley
1703

Filmore Flute

1.5" depth
6" C-C
2" peak
3" valley
1704

304 Standard Spec Flute

0.75" depth
2" C-C
0.75" peak
0.75" valley
1705

305 Standard Spec Flute

0.5" depth
1.5" C-C
0.5" peak
0.5" valley
1706

303 Standard Spec Flute

1.5" depth
2" C-C
0.5" peak
0.5" valley
1707

Lincoln Flute

0.75" depth
6" C-C
2.5" peak
2.5" valley
1708

1/2" Sine Wave

0.5" depth
1" C-C
0.5" peak
0.5" valley
1709

Houston Flute

0.75" depth
1.5" C-C
0.5" peak
0.5" valley
1710

Connecticut Flute

0.5" depth
2" C-C
0.875" peak
0.875" valley
1712

Utah Flute

1-1/2” depth
6" C-C
2-1/2" peak
2-1/2” valley
1713

Colorado Flute

1.5" depth
3" C-C
1" peak
1" valley
1714

Wilson Flute

1" depth
2" C-C
0.75" peak
0.75" valley
1715

San Diego Flute

0.25" depth
0.594" C-C
0.25" peak
0.25" valley
1716

Waimea Flute

0.50" depth
8" C-C
7" peak
1" V-Groove valley
1717

Santa Fe Flute

1.5" depth
6" C-C
1.125" peak
3.875" valley
1718

Arizona DOT Random Flute

1.5" depth
random C-C
random peak
random valley
1720

Taft Flute

1.5" depth
5" C-C
2.5" peak
1.5" valley
1721

307 Standard Spec Flute

0.75" depth
4" C-C
2.5" peak
1.5" valley
1722

1/4" Sine Wave

0.25" depth
0.5" C-C
1723

Wyoming Flute

0.5" depth
6" C-C
4.5" peak
0.5" valley
1724

Mesa Flute

1.5" depth
4.5" C-C
1" peak
2.5" valley
1725

1725 Walters Flute

0.375" depth
1.50" C-C
0.75" squared peaks
0.75" valleys
1726

Orlando Flute

0.75" depth
3" C-C
1" peak
1.5" valley
1730

Colfax Flute

0.75" depth
3" C-C
1.5" peak
1" valley
1731

Random 3/16" Striation

0.1875" depth
random C-C
random peak
random valley
1732

Random Reveal

1" depth
random C-C
random peak
random valley
1734

Adrian Flute

0.75" depth
4" C-C
1.75" peak
1.75" valley
1738

3/8" Flute

0.5" depth
1" C-C
0.375" peak
0.375" valley
1739

Gila Flute

1.25" depth
6" C-C
3.5" peak
1" valley
1740

See9

0.875" depth
2.667" C-C
1741

Perris Flute

0.75" depth
3" C-C
1" peak
1" valley
1744

Varying Striations

0.25" depth
C-C varies
peak varies
valley varies
1745

Standard Spec 309

0.75" depth
3" C-C
0.75" peak
1.75" valley
1751

MTU Flute

1" depth
2" C-C
0.5" peak
0.5" valley
1752

Long Ripple Rib Flute

0.0625" depth
0.375" C-C
1753

Narrow Rippled Rib

0.0625" depth
0.125" C-C
1760

Maui Flute

0.25" depth
1.5" C-C
0.625" peak
0.75" valley
1761

1" Sine Wave

0.5" depth
2" C-C
1765

Franklin Flute

0.5" depth
1.25" C-C
0.375" peak
0.375" valley
1766

6" Sine Wave

1" depth
6" C-C
1767

Chestnut Flute

0.875" depth
6" C-C
4" peak
1" valley
1771

Sawtooth

0.75" depth
1.50" C-C
1.50" wide triangles
1774

Bryan Flute

5" C-C
1-1/2" depth
1775

Spare Rib Flute

1" depth
4" C-C
1.25" peak
2.25" valley
1777

Textured Grave Stake

0.75" depth
random boards
1781

Arizona DOT Random Flute Modified

1" depth
1"-5.5" peak
2"-7" valley
1784

Pinnacle Flute

1" depth
1.5" C-C
1786

3/4" Sine Wave

0.75" depth
2" C-C
1789

WTP Flute

1.5" depth
4.5" C-C
3" peak
0.5" valley
1791

Boat Ramp Flute

0.6875" depth
1.45" C-C
0.0" peak
0.0" valley
5732

6/2 Swell

2" depth sine wave
6" C-C
5730

Map Flute

0.5" depth
12" C-C
11" peak
0.5" valley
5733

Machado Flute

.75" depth
5-1/2" C-C
4" peak
1" valley
5754

5754 Carlsbad Flute

1.5" depth
4" pattern repeat
5939

MBTA Pyramid (Custom)

1" depth
All endpoints to middle of square 4"
5773

Kings Flute

0.75" depth
12" C-C
1.5" triangular valley
1806

Honeycomb

Random 0.25", 0.50", 0.75" and 1" depths
Matching hexagon shapes
1807

Cracked Earth

0.50" maximum depth
1808

Curtains

Random curtain like-striations
2.25" to 5" widths
1" maximum depth
Requires backing
1810

Big Bubble

1" (25mm) bubble height/depth
4'x4' (1.2m x 1.2m) pattern repeat
1811

Circu-llusions

0.5” (12mm) oval depth
4' x 4' (1.2m x 1.2m) pattern repeat
1812

Dou-Bulbs (In)

0.75” (19mm) Feature Depth
18" Feature length
1813

Dou-Bulbs (Out)

0.75” (19mm) Feature Depth
18" Feature length
1815

Mahalo Wave

0.75" Max. Depth
1830

Gardens Chevron 1

30" x 30” repeating motif
1.5" Max. depth
1831

Gardens Chevron 2

36" x 36” repeating motif
1.5" Max. depth
1840

Large Basket Weave

1.25" Max. Relief
12" Tall Weave Rows
20002

20002

1-1/4" base
3/4" top
3/4" height
20003

20003

2" base
1" top
3/4" height
20005

20005

2" base
1" top
1-1/2" height
20008

20008

1-1/4" base
1" top
3/4" height
20011

20011

1-1/4" base
1" top
1" height
20014

20014

2-1/4" base
1-1/2" top
3/4" height
20019

20019

3" base
3" height
20024

20024

3/4" base
3/4" height
20029

20029

3" base
1-1/2" top
3/4" height
20078

20078

1" base
0.88" top
1" height
1106B

1106B Dover Flute

1" depth
2.5" C-C
1" peak
1" valley
1106Wavy

Wavy Dover Flute

1" depth
2.5" C-C
1" peak
1" valley
1107

Mission Flute

1.5" depth
2" C-C
0.75" peak
0.75" valley
1107Custom

1107 Custom

1.5" depth
2" C-C
1108

Washington Rib

1.25" depth
2" C-C
1" peak
0.5" valley
1109

Abiline Rope

1.625" depth
4" C-C
2" peak
2" valley
1110

Bush Rib

1.5" depth
3" C-C
1" peak
1" valley
1111

Harbor Rib

1.5" depth
6" C-C
2" peak
3" valley
1112

JLD Flute

0.625" depth
1" C-C
0.5" peak
0.25" valley
1114

1/2" Fractured Rope

0.5" depth
2" C-C
1" peak
1" valley
1115

Yumpa Rib

0.75" depth
8" C-C
7" peak
1" valley
1116

Jackson Rib

0.375" depth
1.25" C-C
0.4375" peak
0.4375" valley
1117

Split Face Rib

1" depth
4" C-C
3" peak
0.75" valley
1118

Ripped Rope Rib

0.75" depth
3" C-C
1121

Rebar #6

1.25" depth
5.5" C-C
0.75" valley
1123

Vedder Flute

1.375" depth
2" C-C
0.75" peak
0.5" valley
1124

Zaha Rib

1.5" depth
1" peak
3.5" C-C
1.5" valley
1124A

1124A Zaha Rib

1.5" depth
3.5" C-C
1" peak
1.5" valley
1124B

1124B Zaha Rib

1.5" depth
3.5" C-C
1" peak
1.5" valley
1125

Galloway Rib

1.25" depth
2" C-C
0.75" peak
0.75" valley
1127

Extreme Fractured Rib

1.5" depth
2" C-C
0.75" peak
0.75" valley
1128

Utah Rib

0.625" depth
~1.4375 C-C
0.50" peaks
0.50" valleys
1130

Conor Rib

0.75" depth
1.5" C-C
0.75" peak
0.25" valley
1131

Boise Rib

1" depth
4" C-C
3" peak
0.75" valley
1132

Atlantic Rib

1.25" depth
4" C-C
1.875" peak
1.875" valley
1133

Pontiac Rib

1" depth
3.5" C-C
1.5" peak
1.5" valley
1140

Rio Hondo Rib

1.25" depth
3" C-C
1.625" peak
0.75" valley
1142

Long Island Rib

0.5625" depth
1.5625" C-C
0.5625" peak
0.5625" valley
1143

Florida Flute Modified

1" depth
4" C-C
1.5" peak
2" valley
1146

Cimarron Rib

0.625" depth
3" C-C
2" peak
0.75" valley
1147

Napa Rib

1" depth
1.5" C-C
0.5" peak
0.5" valley
1149

Park Rib

1" depth
2.5" C-C
1.25" peak
1" valley
1153

Phoenix Rib

1.125" depth
Random C-C
1154

Walters Flute

0.375" depth
1.50" C-C
0.75" squared peaks
0.75" valleys
1155

T-Rex Rib

1.50" depth
9.625" C-C
7" peaks
2.625" valleys
1161

Honor Rib

1" depth
2" C-C
1.125" peak
0.5" valley
1168

Duke Rib

1/4” (6mm) max. depth
2/3" (17mm) C-C
1171

Colorado Drag

1.5" depth
1.5" - 5"random flute width
1.5" valley
.25" draft
1172

Fox Rib

~1/2” (13mm) max. depth
~4" (100mm) C-C
~3-1/8" (80mm) rib width
~47.25" x 10' (1.2m x 3.05m)
1173

Temecula Rib

1” (25mm) max. depth
1-1/2" (38mm) C-C
5127

1" Extreme Fractured Rib

0.5"-1" (25mm) extremely fractured fin
2" (51mm) pattern repeat
1273

6" Board Planks

6” planks
1/8" (3mm) Max. board variance
1275

Bunyan Planks

Uneven planks with heavy wood grain
8-3/4" to 13-1/2" wide
.75" Max. Relief
1278

Davey Shiplap

3" (76mm) plank width
3/8" (9.5mm) relief
1278

Davey Shiplap

Description line 1 Description line 2 Description line 3
